　　多波段雷達偽裝網以金屬纖維布為基材，采用涂層、切花、綁扎成網。利用金屬纖維的散射特性實現雷達隱身，具有優良的雷達隱身性能。該種偽裝網采用單層平面切花結構，重量較輕，使用方便。利用配套的支撐桿可形成變形遮障，能夠有效消除被遮障目標的光學、紅外、雷達特征。

　　The multi band radar camouflage net is made of metal fiber cloth as the substrate, coated, cut flowers, and tied into a net. Utilizing the scattering characteristics of metal fibers to achieve radar stealth has excellent radar stealth performance. This camouflage net adopts a single-layer flat cut flower structure, which is lightweight and easy to use. The use of supporting rods can form a deformable barrier, which can effectively eliminate the optical, infrared, and radar features of the obstructed target.

　　多波段雷達偽裝網又稱87偽裝網，該系列偽裝網結合新材料、新工藝，采用雷達波散射增強技術，運用復合散射材料，使雷達隱身波段擴展，大大提高了雷達隱身性能，使其由原來的厘米波拓寬到毫米波，并加強了偽裝網面的涂層牢度。特有的熱紅外補償技術，不僅實現熱斑點分割，而且具有熱屏蔽、熱慣量增強作用，使熱紅外隱身性能大大提高。

　　Multi band radar camouflage net, also known as 87 camouflage net, combines new materials and processes, adopts radar wave scattering enhancement technology, and uses composite scattering materials to expand the radar stealth band, greatly improving the radar stealth performance, expanding it from centimeter wave to millimeter wave, and strengthening the coating fastness of the camouflage net surface. The unique thermal infrared compensation technology not only achieves thermal spot segmentation, but also has thermal shielding and thermal inertia enhancement effects, greatly improving the thermal infrared stealth performance.

　　性能指標：1、可見光隱身：顏可以與各種背景顏匹配。2、近紅外隱身：綠偽裝網（或綠斑點）近紅外光譜反射率不小于0.5。3、近紫外隱身：白偽裝網（或白斑點）近紫外光譜反射率不小于0.5。4、熱紅外隱身：使目標與背景的輻射特征接近。5、雷達隱身：對毫米波、厘米波雷達RCS衰減值不小于10dB。6、使用期限：野外連續使用2年以上。7、貯存周期：10年。8、阻燃性能：離火自熄時間10s。9、使用環境：－40～＋50℃。10、單位重量：不大于350g/m2。11、尺寸：可做成任意尺寸，常用的標準尺寸是6800mm×6800mm。

　　Performance indicators: 1. Visible light stealth: The color can match various background colors. 2. Near infrared stealth: The near-infrared spectral reflectance of the green camouflage net (or green spot) is not less than 0.5. 3. Near ultraviolet stealth: The near ultraviolet spectral reflectance of white camouflage nets (or white spots) should not be less than 0.5. 4. Thermal infrared stealth: making the radiation characteristics of the target close to the background. 5. Radar stealth: The RCS attenuation value for millimeter wave and centimeter wave radar should not be less than 10dB. 6. Usage period: Continuous use in the wild for more than 2 years. 7. Storage period: 10 years. 8. Flame retardant performance: self extinguishing time after leaving the fire is 10 seconds. 9. Operating environment: -40 to+50 ℃. 10. Unit weight: not exceeding 350g/m2. 11. Size: It can be made into any size, and the commonly used standard size is 6800mm × 6800mm.
